Dataark
ST5 Series Datasheet.pdfVil du have en bedre pris?
Tilføj til CART og Indsend RFQ Nu, vi kontakter dig straks.
| Antal | Pris per stk | Ext.Pris |
|---|---|---|
| 1+ | $11.563 | $11.56 |
ST5SP81T2C2 Tekniske specifikationer
E-Switch - ST5SP81T2C2 tekniske specifikationer, attributter, parametre og dele med lignende specifikationer som E-Switch - ST5SP81T2C2
| Produktattribut | Attributværdi | |
|---|---|---|
| Fabrikant | E-Switch | |
| Spændingsvurdering - DC | 30 V | |
| Spændingsværdi - AC | 125 V | |
| Afslutningsstil | Quick Connect - 0.250" (6.3mm) | |
| Skiftfunktion | On-Off-On | |
| Serie | ST5 | |
| Panel Cutout Dimensioner | Circular - 12.00mm Dia | |
| Pakke | Bulk | |
| Driftstemperatur | -10°C ~ 125°C | |
| Monteringstype | Panel Mount | |
| Ingress Protection | IP40 | |
| Belysningsspænding (Nominel) | - |
| Produktattribut | Attributværdi | |
|---|---|---|
| Belysningstype, Farve | - | |
| Belysning | Non-Illuminated | |
| Funktioner | - | |
| Elektrisk liv | 10,000 Cycles | |
| Aktuel rating (ampere) | 20A (AC/DC) | |
| Kredsløb | SPDT | |
| Bøsning tråd | 15/32-32 | |
| Basisproduktnummer | ST5SP | |
| Aktuator Type | Flatted | |
| Aktuator Materiale | - | |
| Aktuatorlængde | 22.20mm |
| ATTRIBUT | BESKRIVELSE |
|---|---|
| RoHs Status | Rohs3 -kompatibel |
| Fugtfølsomhedsniveau (MSL) | 1 (Unlimited) |
| ECCN | EAR99 |
| HTSUS | 8536.50.9065 |
De tre dele til højre har lignende specifikationer som E-Switch ST5SP81T2C2.
| Produktattribut | ![]() |
![]() |
![]() |
|
|---|---|---|---|---|
| Varenummer | ST5SP81T2C2 | ST5SP22T1S1 | ST5TP502 | ST5TW103 |
| Fabrikant | E-Switch | E-Switch | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components |
| Monteringstype | Panel Mount | Panel Mount | Surface Mount | Surface Mount |
| Aktuatorlængde | 22.20mm | 16.99mm | - | - |
| Belysningsspænding (Nominel) | - | - | - | - |
| Pakke | Bulk | Bulk | Tape & Reel (TR) | Tape & Reel (TR) |
| Aktuel rating (ampere) | 20A (AC/DC) | 20A (AC) | - | - |
| Spændingsvurdering - DC | 30 V | - | - | - |
| Basisproduktnummer | ST5SP | - | - | - |
| Elektrisk liv | 10,000 Cycles | 10,000 Cycles | - | - |
| Aktuator Materiale | - | - | - | - |
| Ingress Protection | IP40 | IP40 | - | - |
| Aktuator Type | Flatted | Standard Round | - | - |
| Belysning | Non-Illuminated | Non-Illuminated | - | - |
| Serie | ST5 | ST5 | ST5 | ST5 |
| Panel Cutout Dimensioner | Circular - 12.00mm Dia | Circular - 12.00mm Dia | - | - |
| Belysningstype, Farve | - | - | - | - |
| Driftstemperatur | -10°C ~ 125°C | -10°C ~ 125°C | - | - |
| Skiftfunktion | On-Off-On | On-Off | - | - |
| Afslutningsstil | Quick Connect - 0.250" (6.3mm) | Solder Lug | Gull Wing | Gull Wing |
| Spændingsværdi - AC | 125 V | 125 V | - | - |
| Funktioner | - | - | - | - |
| Bøsning tråd | 15/32-32 | 15/32-32 | - | - |
| Kredsløb | SPDT | SPST | - | - |
Download ST5SP81T2C2 PDF -datablad og E-Switch -dokumentation til ST5SP81T2C2 - E-Switch.
